dcstephenson c9dad944e9 Bump VLAN text sizes -- previous export was illegible in the PNG ...

Connector VLAN tags were 7.5px on a ~4000x9400px page -- effectively
invisible unless zoomed in hard inside draw.io itself. Bumped:
- connector labels: 7.5px -> 13px, bold, darker color
- VLAN table: title 11->15px, header 9->12px, rows 9->12px (row/header
  height grown to match, table height computed from the same constants
  so nothing clips)

Page height barely moved (4656 -> 4692px) since only the VLAN panel grew.

Co-Authored-By: Claude Sonnet 5 <noreply@anthropic.com>
Claude-Session: https://claude.ai/code/session_01NM3nivbufxEWiKKmatEtEe

2026-09-15 13:56:23 -05:00

1.8 MiB

3952x9384px
